Discover a ready-to-use laser welding program engineered by JewelWeldTech engineers — optimized parameters for gold, silver, and platinum jewelry repair and fabrication.
Our sample machine program is a fully configured welding profile you can load directly into compatible JewelWeldTech laser systems to reduce setup time and testing.
Pulse width, frequency, and energy levels pre-tuned for common jewelry alloys.
Compatible with 18K/14K gold, sterling silver, platinum, and titanium jewelry pieces.
Validated in JewelWeldTech's lab across hundreds of welding cycles for reliability.
Below is an example parameter set from the sample program file, illustrating recommended settings by material type.
| Material | Pulse Energy (J) | Frequency (Hz) | Pulse Width (ms) | Spot Size (mm) |
|---|---|---|---|---|
| 18K Gold | 8.5 | 5 | 4.0 | 0.3 |
| Sterling Silver | 10.2 | 6 | 3.5 | 0.35 |
| Platinum | 12.0 | 4 | 5.0 | 0.3 |
| Titanium | 9.0 | 5 | 4.5 | 0.28 |
*Values shown are for reference only. Always calibrate according to your specific machine model and workpiece thickness.
Follow these simple steps to import and run the sample machine program on your JewelWeldTech laser welder.
Get the .jwp sample file from the download section below, compatible with JWT-Series machines.
Transfer the file to your machine's control unit using USB drive or local network connection.
Choose the matching material preset from the loaded program and confirm settings on the display panel.
Perform a test weld on scrap material to fine-tune parameters before working on the final piece.
Skip trial-and-error calibration with proven starting parameters.
Achieve repeatable, high-precision welds across production batches.
Minimize scrap and rework caused by incorrect energy settings.
Our engineering team is available to help you customize the program further.
Enter your email to receive the sample machine program file along with a setup guide PDF.
File format: .jwp | Compatible with JWT-200 / JWT-400 / JWT-600 Series
